AWS Code to Custom Cloud Architecture Diagrams

Architecture PatternsArticlesCloud ComputingDevOps 21.4K views

In my last blog, I wrote about how to generate code to custom cloud architecture diagrams using the Diagrams tool .This is an extension to the previous blog, where I have created a similar code and diagram representation for Google Cloud DevOp process.

Here is the custom diagram representation of AWS devOps process

The process was part of the AWS devOps blogs

The code to generate the above diagram is given below

from diagrams import Cluster, Diagram, Edge
from diagrams.custom import Custom

graph_attr = {
    "fontsize": "12",
    "bgcolor": "white",

}

with Diagram("AWS", show=True, graph_attr=graph_attr,direction="LR"):


    developer  = Custom("","./my_aws_extensions/developer.png")

    operationsApproval  = Custom("","./my_aws_extensions/operations-approval.png")


    with Cluster("AWS", graph_attr=graph_attr):

            sourceRepo  = Custom("","./my_aws_extensions/aws-code-commit.png")

            commitEvent  = Custom("","./my_aws_extensions/aws-cloud-watch-event.png")

            ciBuild  = Custom("","./my_aws_extensions/aws-code-build.png")

            ciDeploy  = Custom("","./my_aws_extensions/aws-cloud-deploy.png")

            ciProdDeploy  = Custom("","./my_aws_extensions/aws-cloud-deploy.png")

            buildArtifact  = Custom("","./my_aws_extensions/aws-s3-build-artifact.png")

            pipeline  = Custom("","./my_aws_extensions/aws-code-pipeline.png")

            sourceRepo >> Edge(label="event") >> commitEvent

            commitEvent >> Edge(label="trigger") >> pipeline

            #with Cluster("AWS Pipeline", graph_attr=graph_attr):


            with Cluster("", graph_attr=graph_attr,direction="TB"):
                customBuildTest  = Custom("","./my_aws_extensions/custom-build-test.png")

                devDeploy  = Custom("","./my_aws_extensions/custom-dev-deploy.png")

                prodDeploy  = Custom("","./my_aws_extensions/custom-prod-deploy.png")


            customBuildTest >> Edge(label="pass") >> devDeploy

            devDeploy >> Edge(label="pass") >> prodDeploy


            pipeline >> customBuildTest

            customBuildTest >> Edge(label="trigger build") >> ciBuild

            ciBuild >> Edge(label="store artifacts") >> buildArtifact

            with Cluster("VPC Dev", graph_attr=graph_attr):
                stagingCluster  = Custom("","./my_aws_extensions/stage-cluster.png")


            with Cluster("VPC Prod", graph_attr=graph_attr):
                productionCluster  = Custom("","./my_aws_extensions/production-cluster.png")


            stagingCluster << Edge(label="fetch artifact") << buildArtifact

            devDeploy >> Edge(label="trigger deploy") >> ciDeploy

            ciDeploy >> Edge(label="deploy artifact") >> stagingCluster

            prodDeploy >> ciProdDeploy

            ciProdDeploy >> Edge(label="deploy artifact") >> productionCluster

            productionCluster << Edge(label="fetch artifact") << buildArtifact


    operationsApproval >> Edge(label="Approval") >> prodDeploy

    developer >> Edge(label="commit") >> sourceRepo
